Features

▷ 32-channel optically isolated digital input
▷ 32-channel optically isolated digital output
▷ DC/DC converter built-in
▷ 3000V DC isolation voltage
▷ Four isolated bank

Specification & Introduction

  Isolated Input
▷ Type: Isolated current input
▷ Isolation voltage: 3750V(Using external power); 3000V ( Using internal power)
▷ Input voltage: 3.5V to 30V
▷ Input impedance : 3K (DC 24V, 7.67mA) for each channel
▷ Response time: 10Khz Max

  Isolated Ouput
▷ Open collector: 100mA/channel
▷ External voltage: 30V (Max.)
▷ Response time: 10KHz (Max.)

  Isolated Ouput
▷ Power Requirements: +5V/ 600mA
▷ Operating temp: 0-50°C
▷ Storage temp: -20°C to 70°C
▷ Humidity: 0 to 90% non-condensing
▷ Dimensions: 180 mm x 105 mm

Ordering Information

▷ PISO-P32C32
32-channel Optically Isolated Digital Input and 32-channel Optically Isolated Digital Open-collector output Board (Current Sinking) Includes software : NAPDOS
