PISO-P64

ㆍ▷ 64-channel Optically Isolated Digital Input Board

ㆍ▷ PCI bus interface

ㆍ▷ 64-channel optically isolated digital input

ㆍ▷ DC/DC converter build-in

Manual

Data sheet

Features
▷ PCI bus interface
▷ 64-channel optically isolated digital input
▷ DC/DC converter build-in
▷ Four isolated bank
▷ 3000Vdc isolation voltage

Specification & Introduction

▷ Type : Isolated current input
▷ Isolation Voltage : 3750V( Using External Power); 3000V ( Using internal Power)
▷ Input voltage : 3.5V to 30V
▷ Input impedance : 3K (DC 24V, 7.67mA) for each channel )
▷ Response time: 1Khz Max
▷ Power requirements : +5V 400mA (typical)
▷ Operating temperature: 0-50°C
▷ Storage temperature: -20°C to 70°C
▷ Humidity: 0 to 90% non-condensing
▷ Dimensions: 180 mm x 105 mm

Ordering Information

▷ PISO-P64
 64-channel Optically Isolated Open-collector Digital Output Board (Current Sinking)
Includes software : NAPDOS
