PISO-C64

ㆍ▷ 64-channel Optically Isolated Open-collector Digital Output Board (Current Sourcing)

ㆍ▷ 64-channel optically isolated digital output /open collector

ㆍ▷ Four isolated bank.

ㆍ▷ 3750VDC isolation voltage

Manual

Data sheet

Features

▷ 64-channel optically isolated digital output /open collector
▷ Four isolated bank.
▷ 3750VDC isolation voltage

Specification & Introduction

▷ Type : Isolated open collector : 100mA per channel(NPN)
▷ External voltage : 30V (Max.) Response time: 1Khz Typical
▷ Power requirements : +5V 800mA (typical)
▷ Operating temperature: 0-50°C
▷ Storage temperature: -20°C to 70°C
▷ Humidity: 0 to 90% non-condensing
▷ Dimensions: 180 mm x 105 mm

Ordering Information

▷ PISO-C64
64-channel Optically Isolated Open-collector Digital Output Board (Current Sinking)
Includes software : NAPDOS
