PISO-A64

ㆍ▷ 64-channel Optically Isolated Open-Collector Digital Output Board (Current Sourcing)

ㆍ▷ 64-channel optically isolated digital output /open collector

ㆍ▷ Four isolated bank.

ㆍ▷ 3750VDC isolation voltage

Manual

Data sheet

Features

▷ 64-channel optically isolated digital output /open collector
▷ Four isolated bank.
▷ 3750VDC isolation voltage

Specification & Introduction

▷ Isolation Output
▷ Isolated open-collector: 100mA / each channel
▷ External voltage: 30V (Max.)
▷ Response time: 10KHz (Max)
▷ Power consumption: +5V / 500mA
▷ Operating temperature: 0-50°C
▷ Storage temperature: -20°C to 70°C
▷ Humidity: 0 to 90% non-condensing
▷ Dimensions: 180 mm x 105 mm

Ordering Information

▷ PISO-A64 : 64-channel Optically Isolated Open-Collector Digital Output Board (Current Sourcing)
