PISO-P8R8

ㆍ▷ Isolated 8 Digital Input and 8 Relay Output Board

ㆍ▷ 8 Relay output channels

ㆍ▷ 8 Optical isolated digital input channels

ㆍ▷ DC signal input with filter or W/O filter

Manual

Data sheet

Features

▷ 8 Relay output channels
▷ 8 Optical isolated digital input channels
▷ DC signal input with filter or W/O filter
▷ AC Signal input with filter

Specification & Introduction

  Relay Output
▷ Load current : 1A (Max) per channel
▷ Load Voltage: 30Vdc/220Vac

  Isolated Input
▷ Type : None- polarized opto-isolated (PC-814)
▷ Input voltage : AC/DC 5-24V or VAC(50- 1khz)
▷ Input impedance : 1.2 Kohm
▷ Response time : 20uSec (With out filter) / 22mSec ( With filter)
▷ Isolated : 500v channel-channel

  Environmental
▷ Power Requirements: +5V/ 600mA
▷ Operating temp: 0-50°C
▷ Storage temp: -20°C to 70°C
▷ Humidity: 0 to 90% non-condensing
▷ Dimensions: 175 mm x 121 mm

Ordering Information

▷ PISO-P8R8 : 8- channel Relay Output with isolated digital input Board
