PCI-P16POR16

ㆍ▷ 16-channel isolated digital input , 16-channel PhotoMos Relay Output

ㆍ▷ 16 PhotoMos Relay output channels

ㆍ▷ 16 Optical isolated digital input channels

ㆍ▷ DC signal input with filter or W/O filter

Manual

Data sheet

Features
▷ 16 PhotoMos Relay output channels
▷ 16 Optical isolated digital input channels
▷ DC signal input with filter or W/O filter
▷ AC Signal input with filter

Specification & Introduction

  PhotoMos Relay
▷ Load current : 140mA (Max) per channel
▷ Load Voltage: 250Vac /DC

  Inputs
▷ Type : Non- polarized opto-isolated (PC-814)
▷ Input voltage : AC/DC 5-24V or VAC(50- 1khz)
▷ Input impedance : 1.2K ohm
▷ Response time : 20u Sec (Without filter)
                            22m Sec ( With filter)
▷ Isolated : 500v channel-channel / channel - Ground

  Environmental
▷ Operation Temp. : 0 to 50°C
▷ Storage Temp. : -20°C to 70°C
▷ Humidity : 0 to 90% none-condensing
▷ Dimensions : 180 X 105 mm

Ordering Information

▷ PCI-P16POR16 : 16-channel isolated digital input.16-channel PhotoMos Relay output
