PISO-730

ㆍ▷ 32-channel TTL-level digital I/O ,16-channel Optically Isolated Digital Input and 16 Open-Collector Digital Output Board(Current Sinking)

ㆍ▷ 16 isolated Open-Collector output channels

ㆍ▷ 16 Optical isolated digital input channels

ㆍ▷ 16 Non-isolated TTL digital output

Manual

Data sheet

Features

▷ 16 isolated Open-Collector output channels
▷ 16 Optical isolated digital input channels
▷ 16 Non-isolated TTL digital output
▷ 16 Non-isolated TTL digital input

Specification & Introduction

  Isolated Digital Input
▷ Type : Coommon power isolated Input
▷ Input voltage : DC 5-24V
▷ Input impedance : 1.2 Kohm/1W
▷ Response time : 20uSec (With out filter)
▷ Non-isolated I/O : TTL Levels

  Isolated Digital Output
▷ Load current : 100mA (Max) per channel
▷ Load Voltage: 35V AC /DC

  Environmental
▷ Operation Temp. 0°C to 60°C
▷ Storage Temp: -20°C to 70°C
▷ Humidity: 0-90%, non-condensing
▷ Dimensions: 175mm x 121mm
▷ Power consumption: 5V/600mA

Ordering Information

▷ PISO-730A
32-channel TTL-level digital I/O ,16-channel Optically Isolated Digital Input and 16 Open-Collector Digital Output Board (Current Sinking) Includes software : NAPDOS
