I-7043

ㆍ▷ Non-isolated O.C. Output Module

ㆍ▷ Channels: 16

ㆍ▷ Open collector to 30V max

ㆍ▷ Output current: 100mA per channel.

Manual

Data sheet

Features

▷ Digital Output
  * Channels: 16
  * Open collector to 30V max.
  * Output current: 100mA per channel.
  * Direct drive power relay module

▷ Communication Interface
      RS-485

▷ Power Supply
  * Input: +10 to +30Vdc
  * Power consumption: 0.4W

Specification & Introduction


Ordering Information
▷ I-7043 : Non-isolated O.C. Output Module
