I-7005

ㆍ▷ 8-channel Thermistor Input and 6-channel Alarm Output Module

ㆍ▷ Input Type : Thermistor

ㆍ▷ Input Channels: 8

ㆍ▷ Resolution : 16-bits

Data sheet

Features

▷ Feature
  * Input Type : Thermistor
  * Input Channels: 8
  * Thermistor Type : Precon ST-A3, Fenwell U, YSI L100, YSI L300, YSI L1000, YSI B2252, YSI B3000,
                              YSI B5000, YSI B6000, YSI B10000, YSI H10000, YSI H30000, User-defined
  * Resolution : 16-bits
  * Accuracy : +/-0.1%
  * Sampling Rate : 8 samples/second (Total)
  * -3dB BandWidth : 5.24Hz
  * Common Mode Rejection : Typical 86dB
  * Voltage Input Impedance : >1M Ohms
  * Individual Channel Configurable
  * Wire Opening Detection
  * Alarm Output Type : Open collector
  * Alarm Output Channels: 6  (NPN, Sink) Open collector to 30V, 100mA max. load (per channel)
  * Isolation Voltage : 3000Vdc

▷ Communication Interface
     RS-485

▷ Power Supply
  * Input Voltage Range : +10 ~ +30Vdc
  * Power Consumption :1.3W

Specification & Introduction


Ordering Information
▷ I-7005 : 8-channel Thermistor Input and 6 channel Alarm Output Module
